Analog HD output, up to 1080P resolution
True Day/Night
Smart IR
Up to 20m IR distance
IP66 weatherproof
Metal Case
Description
| Camera | Image Sensor | 2MP CMOS Image Sensor |
| Signal System | PAL/NTSC | |
| Effective Pixels | 1920(H)*1080(V) | |
| Min. Illumination | 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR | |
| Shutter Time | 1/25(1/30) s to 1/50,000 s | |
| Lens | 2.8mm, 3.6mm, 6mm optional | |
| Lens Mount | M12 | |
| Adjustment Range | Pan: 0 - 360°, Tilt: 0 - 180°, Rotation: 0 - 360° | |
| Day& Night | IR cut filter with auto switch | |
| Video Frame Rate | 1080p@25fps/1080p@30fps | |
| HD Video Output | 1 Analog HD output | |
| Synchronization | Internal Synchronization | |
| S/N Ratio | More than 62 dB | |
| General | Operating Conditions | -40 °C - 60 °C (-40 °F - 140 °F) |
| Humidity 90% or less (non-condensing) | ||
| Power Supply | 12 VDC±15% | |
| Power Consumption | Max. 4W | |
| Weather Proof | IP66 | |
| IR Range | Up to 20m | |
| Dimension | Φ70×149.5 mm (Φ2.76” ×5.89”) | |
| Weight | 400 g |
