1/4" 1Megapixel CMOS
25/30 fps@720P
High speed, long distance real -time transmission
HD and S D switchable
OSD Menu, control over coaxial cable
DWDR, Day/Night(ICR), AWB, AGC, BLC , 2DNR
2.8mm Fixed lens
Max. IR LEDs length 20m, Smart IR
DC12V
Description
| Model | BLS-122-QT | |
| Camera | Image Sensor | 1/4" 1Mega pixel CMOS |
| E ective Pixels | 1280(H)×720(V) | |
| Electronic Shutter | PAL: 1/25~1/100000s dan NTSC: 1/30~1/100000s | |
| Video Frame Rate | "25/30fps@720P | |
| Synchronization | Internal | |
| Min. Illumination | 0.05Lux/F2.0, 0Lux IR on | |
| Video Output | 1-channel BNC high de nition video output/ CVBS standard de nition video output (Can switch ) |
|
| Camera Features | Max. IR LEDs Length | 20m, Smart IR |
| Day/Night | Auto( ICR)/Color/B/W | |
| Backlight Compensation | DWDR | |
| Noise Reduction | 2D | |
| OSD Menu | Support | |
| Lens | Focal Length | 3.6mm (2.8mm Optional) |
| Angle of View | H: 60° ( 83.4°) | |
| Mount Type | Board-in | |
| General | Power Supply | DC12V± 25% |
| Power Consumption | Max 2.8W | |
| Working Environment | -40°C~+60°C / Less than 95% RH (no condensation) | |
| Transmission Distance | Over 800m via 75 -3 coaxial cable | |
| Dimensions | 154.3mm×69.8mm×69.8mm (6.07"×2.75"×2.75") | |
| Weight | 0.15kg | |
| Material | Plastic | |
