HIKVISION NVR DS-7600NI-E1/A/1T

HIKVISION NVR DS-7600NI-E1/A/1T
Model DS-7600NI-E1/A/1T
Video/Audio input IP video input 8-ch
Two-way audio 1-ch, RCA (2.0 Vp-p, 1k)
Video/Audio output Recording resolution
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF

CVBS output 1-ch, BNC (1.0 Vp-p, 75 )
Resolution: 704 576 (PAL); 704 480 (NTSC)
LCD output 1-ch, resolution: 1024 x 768/60Hz,1280x 720/60Hz,1280 x 1024/60Hz, 1600 x 1200/60Hz, 1920x 1080/60Hz
VGA output 1-ch, resolution: 1920 x 1080/60Hz,1600 x 1200/60Hz,1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
Audio output
1-ch, RCA (Linear, 1K) to output NVR audio; 1-ch 3.5mm audio jack;2-ch stereo loudspekers

Note : alternative in 3.5mm audio jack and loudspeaker

Playback resolution
720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF

Synchronous playback 16-ch
Hard disk SATA 1 SATA interfaces for 1 HDD
eSATA 1 eSATA interface
Capacity 2.5inch, 500G/1T
External interface Network
interface Incoming bandwidth 80Mbps
Incoming bandwidth 80Mbps
Serial interface
1RS-485 interface, 1 RS-232 interface, 1 RS-485 keyboard interface

USB interface 2, USB2.0
Alarm in 16-ch
Alarm out 4-ch
Others Power supply 12 VAC (1 AC adaptor)
Consumption
(without hard disk or
DVDR/W) 36W
Working temperature 0 ~ +50 oC(32oF ~ 122 oF)
Working humidity 10 % ~ 90 %
