Key Features :
1/3" DIS 700TVL
1280(H) x 960(V) Pixels
True Day / Night
3.6mm fixed lens (2.8mm, 6mm optional)
Max. IR LEDs length 80m, EXIR
DC12V 4W, IP66
Specification :
Image Sensor : 1/3" DIS 700TVL
Effective Pixels : 1280(H) x 960(V)
Electronic Shutter : 1/25s~1/25,000s
Video Frame Rate : 25/30fps
Synchronization : Internal
Min. Illumination : 0.1 Lux @(F1.2, AGC On), 0 Lux With IR
Video Output : 1 composite output
Max. IR LEDs Length : 80m, Smart IR
Day / Night : ICR
S / N Ratio : More than 62dB
Focal Length : 3.6mm (6mm, 8mm, 12mm, 16mm optional)
Angle of View : 71.4(3.6mm)
Mount Type : M12
Power Supply : 12 VDC
Power Consumption : Max 5W
Working Environment : -40C~+60C / Humidity 90% or less (non condensing)
Dimensions : 105104.8263.1mm
Weight : 1.200g
