| TV System | Type | PAL | |
| Camera | Image Sensor | 1/4 inch interline transfer CCD | |
| Effective Pixels | 752 (H) x 582 (V) | ||
| Scanning Mode | 2:1 interlace scan | ||
| Scanning Area | 0.37 (H) x 0.27 (V) cm | ||
| Scanning Frequency | Horizontal | 15.625 kHz | |
| Vertical | 50 Hz | ||
| Scanning Line | 625 lines | ||
| Horizontal Resolution | 540 TV lines | ||
| Minimum Illumination | Color: 1.2 lux at F2.0 B/W: 0.9 lux at F2.0 |
||
| Signal-to-Noise Ratio | 50 dB (Equivalent to AGC Off) | ||
| White Balance | ATW | ||
| Light Control | ELC only (for lens adjustment) | ||
| AGC | Always ON | ||
| Adaptive Black Stretch | ON / OFF with BLC ON / OFF | ||
| Black and White Mode | ON (Auto) / OFF (No IR filter moving) | ||
| Back Focus Adjustment | Manual | ||
| Synchronization | Internal (INT), Multiplexed Vertical Drive (VD2) | ||
| Lens | Focal Length | 0.25 cm | |
| Angular Field of View | H: 90° V: 65° | ||
| Maximum Aperture Ratio | F2.0 | ||
| Focusing Range | 1.2 m ~ ∞ (3.9 ft. ~ ∞) | ||
| Pan and Tilt | Panning Range | +180° ~ –140° | |
| Tilting Range | ±75° Image tilt adjustment range: ±160° | ||
| Input / Output | Video Output | 1.0 V [P-P] / PAL composite 75 Ω / BNC Connector Multiplexed VD2 capable | |
| General | Setup Method | Dip Switch | |
| Safety/EMC Standard | CE (EN55022 ClassB, EN55024), GOST (GOST R 51558) | ||
| Power Source and Power Consumption | WV-CW240S | 12 V DC, 180 mA | |
| Ambient Operating Temperature | –10 °C ~ +50 °C (14 °F ~ 122 °F) | ||
| Ambient Operating Humidity | 90 % or less (without condensation) | ||
| Dimensions | ø10.8 x 8.3 cm (H) | ||
| Weight (approx.) | 280 g (0.62 lbs.) | ||
| Note | *Weights and dimensions are approximate. *Specifications are subject to change without notice. |
||
