| Camera |
Image Sensor |
1/4 type interline transfer CCD |
| Effective Pixels |
976 (H) x 582 (V) |
| Scanning Mode |
2:1 interlace |
| Scanning Area |
0.36 (H) x 0.27 (V) cm |
| Scanning Frequency |
Horizontal: 15.625 kHz Vertical: 50.00 Hz |
| Horizontal Resolution |
650 TV lines |
| Minimum Illumination |
Color:0.5 lx (Sens Up: Off, AGC: High), B/W: 0.04 lx (Sens Up: Off, AGC: High) |
| Signal-to-Noise Ratio |
52 dB (AGC: OFF) |
| White Balance |
AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 8,000 K), ATW2 (2,400 ~ 8,000 K) |
| Light Control |
ALC (Adjustable OPEN/CLOSE output target level) / MANUAL |
| AGC |
ON (LOW, MID, HIGH) / OFF |
| Super Dynamic 6 |
ON / OFF (WV-CZ492) |
| Dynamic Range |
54 dB typical (Super Dynamic 6 : ON) (WV-CZ492) |
| Electronic Shutter |
OFF (1/50), AUTO, 1/120, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000 |
| Electronic Sensitivity UP |
32x max. AUTO, 512x max. FIX |
| Digital Noise Reduction |
High or Low |
| Black and White Mode |
Auto / ON / OFF /EXT |
| Scene File |
10 patterns (Shutter, AGC, Sens UP, White balance, VMD) |
| Scene Select Setting |
INDOOR (L) / INDOOR (H) / OUTDOOR (L) / OUTDOOR (H) |
| Video Motion Detection |
OFF / MOTION DET / SCENE CHANGE |
| Privacy Zone |
ON (1) / ON (2) / OFF, up to 8 zones |
| Auto Image Stabilizer |
ON / OFF |
| Camera Title |
16 alphanumeric characters |
| Auto Focus |
STOP AF /AUTO |
| Synchronization |
Internal (INT) |
| Lens |
Focal Length |
0.33 cm ~ 11.9 cm |
| Zoom Ration |
36x (Approx. 720x with digital zoom) |
| Zoom Speed |
approx. 6.0 seconds (Tele ~ Wide) in manual mode |
| Zoom Limit |
1x ~ 720x (Over 36x is digital zoom) |
| Angular Field of View |
H: 1.47° (Tele) ~ 60.15° (Wide), V: 1.20° (Tele) ~ 46.03° (Wide) |
| Maximum Aperture Ratio |
1:1.4 (Wide) ~ 4.2 (Tele) |
| Focusing Range |
1.5 m (4.9 ft.) ~ ∞ |
| Aperture Range |
F1.4 ~ 22, Close |
| Input / Output |
Video Output |
1.0 V [p-p] / PAL composite 75 Ω |
| Controller Interface |
Coaxial Multiplex System, RS485 (Panasonic, Pelco P/D) |
| External I/O Terminals |
4 inputs (ZOOM, FOCUS, IRIS, D/N IN), 1 output (ALARM) |
| Day/Night IN |
Input pulled up to 5.0 V DC OFF (open or 4 V DC - 5 V DC) /ON (0 V 0.2 mA) |
| General |
Setup Method |
OSD setup menu |
| Password Lock |
All menus |
| Language |
English, French, Italian, Spanish, German, Russian, Chinese, Japanese |
| Safety/EMC Standard |
CE (EN55022 ClassB, EN55024), GOST (GOST R 51558) |
| Power Source and Power Consumption |
12 V DC, 220 mA |
| Ambient Operating Temperature |
–10 °C ~ +50 °C (14 °F ~ 122 °F) |
| Ambient Operating Humidity |
90 % or less (without condensation) |
| Dimensions |
5.8 cm (W) x 11.8 cm (H) x 6.8 cm (D) |
| Mass (approx.) |
310 g |
| Finish |
ABS resin / Black |
